Vertical CHYLED700 LED Shadowless Surgical Light, Adjustable Color Temp Cold Light Operating Lamp with Backup Battery for Hospital Operation Room

Core Performance Advantages

1. Long-Life Cold LED Light Source

   Adopts new cold LED light source with service life over 60,000 hours, no frequent bulb replacement needed, energy-saving and eco-friendly compared with traditional halogen lamps. No ultraviolet or infrared radiation; temperature rise on doctor’s head and surgical wound ≤1℃.

2. Laminar Flow Aerodynamic Lamp Head

   Fully enclosed streamlined lamp head eliminates air flow dead zones, satisfies high-standard laminar flow and sterile requirements of modern operating rooms, easy to clean and disinfect.

3. Adjustable Brightness & Color Temperature

   Color temperature adjustable from 3500K to 5000K to prevent eye fatigue for medical staff during long surgeries. Optional touch LCD control panel supports one-key switch, stepless adjustment of illuminance, color temperature and lighting modes.

4. Deep Uniform Lighting Effect

   High-performance lens gathers LED beams into uniform high-brightness light column, providing soft and deep focused illumination to meet high brightness and deep lighting demands of complex surgeries. Max illuminance reaches 160,000 Lux, each lamp module supports independent brightness regulation.

5. Flexible 360° Balanced Suspension Arm

   Lightweight high-quality balanced arm (imported arm optional) with six universal joint linkages, 360° full rotation, freely adjustable height, angle and position for all surgical postures.

6. Sterilizable Manual Focus Handle

   Manual stepless focusing design solves LED focusing technical difficulties. Detachable disinfection handle supports high-temperature sterilization under ≤160℃.

7. Low Failure Rate Independent LED Modules

   Each LED module contains 6-10 OSRAM LED beads with independent electronic control system. Single LED damage will not affect the overall operation of the lamp head, greatly reducing maintenance costs.

8. Mobile Base with Stable Braking Casters

   Four-wheel support base with thickened steel counterweight and silent lockable casters, flexible to move and firmly fixed at any position during operation.

9. Built-In Emergency Backup Battery

   Equipped with internal storage battery, it automatically switches power supply during power outages to guarantee continuous surgical lighting anytime.


   Technical Parameters

   • Model: CHYLED700 Vertical Surgical Lamp
   • LED Quantity: 80 pcs OSRAM LED beads
   • Illuminance: 80,000 – 160,000 Lux
   • Adjustable Color Temperature: 3500K – 5000K
   • Light Spot Diameter: 150mm – 350mm
   • Dimming Mode: Stepless dimming system
   • CRI (Color Rendering Index): ≥96
   • Color Reproduction Index: ≥97
   • Illumination Depth (20%Ec): ≥1200mm
   • Illumination Depth (60%Ec): ≥800mm
   • Temperature Rise on Doctor’s Head: ≤1℃
   • Temperature Rise on Surgical Field: ≤2℃
   • Power Supply: 220V / 50Hz
   • Input Power: 400W

   Standard Configuration List

   1. 700 Lamp Head ×1 set (1 spare lamp head included)
   2. Sterilizable Disinfection Handles ×2 pcs
   3. Germany OSRAM LED Light Group ×1 set
   4. Balanced Suspension Arm ×1 set (imported arm optional)
   5. Switch Power Supply Assembly ×1 set
   6. Built-In Backup Battery ×1 set
   7. Vertical Lamp Column ×1 set
   8. Mobile Support Base with Brake Casters ×1 set
   9. Matching Maintenance Tools ×1 set
   10. Product Certificate & Warranty Card ×1 set
   11. Operation Manual ×1 set

   Application Scenarios

   General surgery rooms, plastic surgery clinics, emergency treatment rooms, outpatient examination rooms, veterinary operating rooms, beauty medical institutions, suitable for suture, minor surgery, cosmetic operation and routine surgical diagnosis.
